22 racks
Standard rack size 16 x 16
Functions and Benefits
Fagors Concept range of dishwashers combines features and
benefits that only high-end ranges are offering, establishing a
product easy to use and efficient, with the most effective and robust
technology prepared for the strongest usage of the market. Built
with durable stainless steel, electromechanical components
and simple digital controls with temperature display for a userfriendly operation.
Effi Wash: Optimized hydraulic system provides a strong mechanical action combined with the optimum clean water in the tank. Balanced power keeps the perfect sanitation temperature during the cycle of the wash.
Soft Start: Wash-pump power control that prevents wares from damage at the beginning of the washing cycle while assuring a low noise level in your facility.
Digital Controls: Simple digital control panel with temperature display for intuitive and user-friendly operation, IPX-4 proof.
Construction
Heavy duty stainless steel construction front, top and sides.
Double skin door to reduce noice during operations.
AISI-304 Stainless.
IPX4 - Stronger protection against water hose cleaning and external humidity.
Built-in drain pump, detergent and rinse aid dispenser.
Built-in pressure gauge.
Acessories:
Racks for glasses
Rack dividers
Cutlery containers and grids
6 & 16 high base stands
Drain tempering valve
QuickView:
Dimensions W x D x H: 18-1/2 x 20-5/8 x 28-1/8
Weight net/crated (lbs): 97 / 103
Voltage: 208-230V/1Ph/60Hz
Total Power: 3.2 KW
Wash pump ( HP ): 1/3
Water Consumption Per Rack: 0.53 Gal.
Water Comsumption Per Hour (Max): 11.66 Gal.
Weight net/crated (lbs): 97 / 103
Voltage: 208-230V/1Ph/60Hz
Total Power: 3.2 KW
Wash pump ( HP ): 1/3
Water Consumption Per Rack: 0.53 Gal.
Water Comsumption Per Hour (Max): 11.66 Gal.
